Mil-Std Gen2+/Gen3 NVM PVS14

Model: DTS-14

Short Description:

The DTS-14 night vision is a new product developed based on the latest optoelectronics technology
with a field of view of 50 degrees.The magnification can be
changed by replacing the objective lens. The night vision device has a built-in infrared Illuminator and
an auto- gain system.

Product Detail

Product Tags

838b00418ba9c590c995627edd4efb8



Main Features

1. IP65 waterproof standard(IP67 optional);
2. Build in IR indicator and low battery indicator;
3. Optical distortion less than 0.5%;
4. Mil-spec multi-coated optics;
5. 30mm diameter eyepeice lens;
6. Longer eye relief 25-40mm with full FOV;
7. Normal use CR123A battery, also offer AA battery version;
8. AUTO shut OFF/ON when flip up/down, save power when not use;
9. Offer 3X and 5X magnifier lens;
10. Eyepiece lens and objective lens coated with demist coating;
11. Offer sacrificial windows(optional);
12. Strong light auto shut off;

Technical specifications:

MODE DTS-14
Generation Gen 2+/Gen3(optional)
Magnification 1X
Resolution ( lp/mm) 60-64
S/N (dB) 18-24
Luminous sensitivity(uA/lm) 600-800
FOV(°) 50+/-2  (40 optional)
Diopter -6~+4  / -4~+6
Capability Flip-Up On-Off
Automatic Brightness Control YES
Bright Light Cut-off YES
Infrared Illuminator Built-in(850nm 10mW)
IR Indicator YES
Low Battery Indicator YES
Optical distortion <0.5%
Pupil distance(mm) 20-45
Battery Voltage 1.2-1.6V/2.4-4.2V
Battery type CR123(A)x1/AA(1)
Temperature range(℃) -40/+55
Humidity range 5%-98%
Waterproof IP65(IP67 optional)
Dimensions(mm) 110x63x42
Weight(no battery) 180g(housing)/240g(finished)
