Tactical Hunting Gen2+/Gen3 Thermal NVG DTG-22

Model: DTS-22

1.FOV 50 ° and FOV 40°(optional) ，We are the only that can achieve FOV 50° .

2. Special design, adopted folding light path and veneer design, low cross section structure.

3.High-fidelity image, and no distortion in the observation screen.

4. Built-in working indicator, keep abreast of the using status.

5.In the auto mode, the IR is adjusted by environment brightness.

6.Long and short IR light can be selected.

7. Self-developed special materials, high strength, high temperature resistance, light weight, and battery radiation resistance.

8. Center of gravity back, close to the face, head wear comfortable, lightweight to wear

9. We achieved Flip up down ON/OFF and side up down ON/OFF.

10. Universal battery design, both CR123 battery and AA battery can be used.

11. The waterproof can reach IP65/IP67.

Send email to us

Technical specifications:

MODE	DTS-22N	DTS-22T(Fusion)
Generation	Gen 2+/Gen3(optional)	Gen 2+/Gen3(optional)
Magnification	1X	1X
FOV(°)	50+/-2	50+/-2
Diopter	+ / – 5	+ / – 5
Battery type(v)	CR123A(1)/AA / Battery pack	CR123A(1) /Battery pack
Power supply(v)	2.5-4.2	2.5-4.2
Battery capacity	300-3200maH	600-3200maH
Total Darkness IR System	YES	YES
Automatic Brightness Control	YES	YES
Bright Light Cut-off	YES	YES
Infrared Illuminator	Built-in(850nm 20mW)	Built-in(850nm 10mW)
IR Indicator	YES	YES
Low Battery Indicator	YES	YES
Optical distortion	0.5% Max	0.5% Max
Relative Illumination	>75%	>75%
Distance of pupil	25-30mm	25-30mm
Eyepiece aperture	9mm	9mm
Display resolution		1280×720
Thermal image wavelength		8-12uM
Thermal image resolution		384×288
Fusion mode		Optical fusion
Operating temperature(℃)	-40–+55	-40–+55
Relative humility	5%-95%	5%-95%
Waterproof	IP65/IP67	IP65/IP67
Dimensions(mm)	81x132x81	81x140x90
Weight(g)	320g(housing)/390g(finished)	355g(housing)/425g(finished)
